Boom Lift GTBZ 30

Categories: , SKU: ARTICULATED-ELECTRIC-1 Brand:

Sinoboom’s self-propelled Telescopic Boom Lifts offer rugged, excellent performance and reliabililty,

to provide users with a safe and adaptable MEWP that meets challenging conditions and requirement needs.

Self-propelled capability during aerial operations increases flexibility and productivity

Loading...

Description

Platform Capacity (Unrestricted) 250kg (551lbs)

Platform Capacity (restricted) 454kg (1,000lbs) / 300 kg (661lbs)

Turntable Rotation 360° /Continuous

Platform Rotation 160°

Drive Speed-Stowed 0 ～ 4.8 km/h （0 ～ 3 mph）

Drive Speed-Raised 0 ～ 1.1 km/h （0 ～ 0.68 mph）

Gradeability 45%

Turning Radius-Inside 3.65m (12′)

Turning Radius-Outside 6.91m (22’8″)

Turntable Tailswing 1.45m (4’8”)

Tilt Rating 5°

Max Operating Noise Level

Drive×Steer 4WD×2WS

Tyres-solid 385/65D22.5 (Foam-filled)
