| Model |
|
F500.RS2-V |
| Attachment type |
|
20’/40′ Top Pick Spreader |
| Load capacity on tires at 1st/2nd/3rd row (no stab) |
kg |
45.000 | 31.000 | 16.000 |
| Load centre distance at 1st/2nd/3rd row |
mm |
1.780 | 3.850 | 6.400 |
| Load capacity on stabilizers at 1st/2nd/3rd row * |
kg |
Stabilizers not available |
| Load centre to front face of the truck |
mm |
830 |
| Lifting height under twist-lock |
mm |
15.100 |
| Stacking Ability – containers |
|
5 = 5 x 9’6” |
| Wheelbase |
mm |
6.500 |
| Service weight – unladen |
kg |
71.800 |
| EU Stage IIIA Engine make&model (Rated Power) |
(kW) |
CUMMINS X12 (250) |
| EU Stage V Engine make&model (Rated Power) |
(kW) |
CUMMINS X12 (250) |
| Transmission make&model |
|
DANA TE30 |
| Service Brakes |
|
Cooled wet disk brakes |
