FORKLIFT TRUCKS-4X4
SUPER HEAVY DUTY FORK LIFT TRUCKS
Description
| Model |
|
FH40C |
| Attachment type |
|
Coil ram |
| Load capacity on tires |
kg |
40.000 |
| Load centre distance (+/- out/in rach) |
mm |
1.200 |
| Load centre to centre of front axle |
mm |
2.380 |
| Standard lifting height on forks (option) |
mm |
4.000 |
| Max available lift height on forks (option) |
mm |
8.000 |
| Wheelbase |
mm |
5.000 |
| Service weight (unladen) |
kg |
55.600 |
| EU Stage IIIa Engine make&model (Rated Power) |
(kW) |
CUMMINS X12 (250) |
| EU Stage V Engine make&model (Rated Power) |
(kW) |
CUMMINS X12 (250) |
| Transmission make&model |
|
DANA TE30 / 5-3 |
