Description
Throughput Capacity 3 m3/ hour
Paper Crushing Capacity Until 700 kg/hour
Plastic Crushing Capacity Until 300 kg/hour
Motor Capacity 7.5 – 18 kW
Hopper Opening 975 x 830 mm
Erection Area 2.120 x 1.650 m (L x W)
Power Source 20 Hp (2×10) 3-phase motor operated
Motor Make Crompton (IE2 Motor – 1440 rpm – 1 Year warranty)
Working Area 600 x 350 mm
Cutter Thickness 15 mm
Cutter Material Hardened Alloy Steel
Cutter Dia 200 mm
Shaft Material Hardened Alloy Steel
Chamber Two nos. of shafts holding heavy by bearing plate
Bearings Spherical bearing (4 nos.)
Gear Box Helical – 20-25 rpm
Gear Box Build Power builder
Body Material Painted MS plates and C-channel for basic frame portion
Cleaner Double stage, Built side wall with gun metal bush and oil seal protection for water resistance.
Control System Automatic forward and reverse control panel with tower lamp and emergency stop on the machine
