Description
Capacity Per Hour 40-50 barrels
Compression Force 270 KN
Motor Capacity 7.5 KW
Barrel Type Light Sheet Metal
Barrel Size 618 X 1092 mm
Machine Weight 970 KG
Dimensions Of Machine 1168 X 960 X 2892 (W x H X D)
Compression Force (Horizontal) 140 KN
Opening of Fills Door 1200 X 800 mm
Producing Bales Dimensions 900 x 800 x 600 mm (L x W x H)
Baling Chamber 635 x 762 x 1397 mm (H X W X L)
Bale Size 381 x 381 mm (H x W)
Electric Motor 25+2 HP, 3-phase, 1440 rpm
Hard Liner Plates Provided (C 45)
Body Fabricated 45+12 mm
Oil Drive Double Pump Systems
